Features

Adjustable steering wheel

Toyota seat with safety belt

LED front work lights

Warnings lights

Rear tail lights

Warning buzzer

Tool box

Specifications

Rated Capacity:

2,000kg

Load Center:

600mm

Front Overhang:

320mm

Wheelbase:

1,760mm

Service Weight:

7,510kg

Wheel Type:

Solid

Load Wheel:

457 x 178mm

Drive Wheel:

415 x 178mm

Mast Tilt Range:

1/3

Lift Height:

8,000mm

Overhead Guard Height:

2,255mm

Seat Height:

1,230mm

Overall Height:

3,870mm

Overall Width:

1,450mm

Fork Size:

1,070 x 122 x 40mm

Fork Carriage Width:

990mm

Forks Outside Width:

480-890mm

Side Shifting Distance:

+/- 100mm

Mast Ground Clearance:

70mm

Body Ground Clearance:

100mm

Turning Radius:

2,300mm

Driving Speed:

12km/h loaded, 15km/h unloaded

Max Gradeability:

12° loaded, 15° unloaded
